Atlas 61
Atlas 61 is a compact 61 MP full-frame imaging camera designed for high-resolution aerial mapping, inspection and surveillance.
Typical Applications
Drone Mapping · ISR · Long-Range Surveillance · Infrastructure Inspection · Photogrammetry · Space Domain Awareness · Scientific Imaging · Aerial Survey
Imaging Performance
61 MP Full-Frame Sony IMX455
For high-detail aerial imaging, mapping, inspection and long-range observation.
3.76 µm Pixel Size
Fine spatial sampling for high ground resolution and angular detail.
16-bit Imaging
Preserves detail across bright and dark areas for demanding imaging applications.
High-Resolution ROI Support
Region-of-interest acquisition for faster processing and target tracking.
Optics & Camera Control
Canon EF Lens Support
Compatible with a broad range of Canon EF prime and zoom lenses.
Electronic control of lens focus and aperture directly from the camera system.
Interchangeable Optics
Quickly adapt field of view and ground resolution to different missions simply by changing the lens.
Remote Camera Control
Remote control of exposure and lens settings from the host system.
Designed for integration with onboard computers.
Gimbal Integration
Designed for integration with Gremsy gimbals and other UAV payload systems.
UAV Integration & Sync
Hardware Trigger Support
Precise image acquisition and synchronisation with external systems.
Accurate Image Timestamping
Supports correlation of imagery with GNSS/INS, aircraft position and attitude data.
Weight & Dimensions
Approx. 800 g with 50 mm lens
Camera body: 110 × 90 × 95 mm (without lens)
Helios 1.31
Helios 1.31 is a compact SWIR camera that enables improved imaging through haze and challenging atmospheric conditions while providing enhanced contrast for a wide range of materials and targets.
Typical Applications
ISR · Long-Range Surveillance · Infrastructure Inspection · Aerial Survey · Remote Sensing · Search & Rescue · Environmental Monitoring · Scientific Imaging
Imaging Performance
1.34 MP Sony IMX990 SWIR Sensor
High-sensitivity InGaAs SWIR sensor with 1296 × 1032 effective resolution providing compact high-performance imaging for UAV inspection, surveillance and remote-sensing applications.
5 µm Pixel Size
5 × 5 µm pixels provide fine spatial sampling
SWIR Imaging from 1.1µm to 1.7 µm
Enables enhanced contrast and material differentiation in challenging imaging conditions.
High-Speed ROI Support
Region-of-interest acquisition allows reducing bandwidth and processing requirements for detection, tracking and machine-vision applications.
Optics & Camera Control
C-Mount Lens Support
Compatible with a broad range of compact C-mount SWIR and VIS-SWIR lenses.
SWIR-Optimized Optics
Designed for use with optics optimized for the 0.9–1.7 µm spectral range, helping preserve image quality, transmission and contrast across the SWIR band.
Remote Camera Control
Remote control of exposure and lens settings from the host system.
Designed for integration with onboard computers.
Gimbal Integration
Designed for integration with Gremsy gimbals and other UAV payload systems.
UAV Integration & Sync
Hardware Trigger Support
Precise image acquisition and synchronisation with external systems.
Accurate Image Timestamping
Supports correlation of imagery with GNSS/INS, aircraft position and attitude data.
Lightweight Camera Body
Compact mechanical design intended to minimise payload weight while maintaining robust thermal and mechanical performance.
Weight & Dimensions
Camera body dimensions and final system weight depend on the selected optics and mechanical configuration.
